1N4007 Rectifier Diode

Description

Technical Overview of the 1N4007 Rectifier Diode

The 1N4007 Rectifier Diode is the world’s most widely used general-purpose silicon rectifier. Designed for low-frequency power rectification, it is a staple component in almost every electronic device that converts AC to DC. Rated at 1A and 1000V, this diode is extremely versatile and capable of handling high voltage surges with ease. At BuyCircuitParts, we supply high-standard 1N4007 diodes that ensure your power supply projects stay robust and “on track.”

Key Specifications and Functional Parameters

To ensure this component fits your circuit, here are the technical specifications in plain text:

• Peak Repetitive Reverse Voltage (VRRM): 1000V.

• Average Forward Rectified Current (IF): 1.0 Ampere.

• Non-Repetitive Peak Forward Surge Current: 30A.

• Forward Voltage Drop (VF): 1.1V at 1.0A.

• Operating Junction Temperature: -65C to +175C.

• Package Type: DO-41 (Axial Lead).

Why Choose the 1N4007 for Power Rectification?

The 1N4007 Rectifier Diode is preferred for its massive 1000V reverse voltage rating, which provides a significant safety margin against power line spikes. Unlike fast-recovery diodes, the 1N4007 is optimized for 50Hz to 60Hz AC rectification, making it highly efficient for standard power adapter builds. At BuyCircuitParts, our 1N4007 stock features a low leakage current and high reliability, ensuring that your energy conversion remains stable and “on track” during continuous operation.

Common Applications for the 1N4007 Diode

The 1N4007 Rectifier Diode is essential for these common electronic tasks:

1. Full-Wave Bridge Rectifiers: Converting household AC into usable DC for electronics.

2. Battery Chargers: Preventing reverse current flow from the battery to the charger.

3. Reverse Polarity Protection: Protecting sensitive components if a power supply is connected incorrectly.

4. Clamping Circuits: Limiting voltage spikes in low-frequency power stages.

5. General Prototyping: A “must-have” component for every electronics hobbyist and engineer.

Pro-Tips for Circuit Integration

To maximize the performance of your 1N4007 Rectifier Diode, follow these professional tips:

• Polarity Awareness: Always identify the cathode (negative side) by the silver band on the black epoxy body.

• Bridge Rectifier Assembly: Use four 1N4007 diodes in a bridge configuration for full-wave rectification.

• Soldering Lead Length: Leave at least 5mm of lead between the diode body and the solder joint to allow for proper thermal expansion.

• Current Limits: For projects requiring more than 1A, consider wiring diodes in parallel or stepping up to the 1N5408 (3A) series to stay “on track.”

Durability and Reliability

The 1N4007 Rectifier Diode is built to withstand harsh electrical environments. Its rugged DO-41 package is designed for easy mounting and excellent heat dissipation through the axial leads. With a high junction temperature tolerance, this diode can operate reliably even in compact power enclosures with limited airflow. By sourcing from BuyCircuitParts, you get diodes that meet strict industrial standards for forward current and reverse breakdown voltage.

Why Buy from BuyCircuitParts?

Consistency is key in manufacturing. At BuyCircuitParts, our 1N4007 Rectifier Diode inventory is tested to ensure every batch performs exactly as the datasheet specifies. We understand that even a simple diode is critical to your project’s success. Our commitment to high-quality hardware and fast shipping helps you avoid delays and keeps your production “on track.”

📐 Approx Dimensions (DO-41 Package):
Body Diameter: ~2.5 mm
Body Length: ~5.2 mm
Lead Diameter: ~0.8 mm
Lead Length: ~25 mm each side

🧊 Note:
Product colour and markings may vary slightly based on manufacturer and batch. Functionality is guaranteed. (Refer to the product image for illustration only. For precise specifications, consult the datasheet.) For a deeper understanding of diode recovery times, visit the Diode Wikipedia Page.
