5.6k Ohm 0.5watt 5% Carbon Film Resistor

Description

Technical Overview of the 5.6k Ohm 0.5watt 5% CFR Resistor

The 5.6k Ohm 0.5watt 5% CFR Resistor is a fundamental passive component used extensively in both analog signal processing and digital control systems. With a resistance of 5,600 Ohms, it is a “sweet spot” value for op-amp feedback loops and transistor collector biasing. The 0.5W (half-watt) power rating provides a significantly higher thermal ceiling than standard 0.25W resistors, allowing for cooler operation and improved long-term reliability in dense circuit boards. At BuyCircuitParts, we supply industrial-grade 5.6k Ohm CFRs to ensure your audio equipment and sensor interfaces stay calibrated and “on track.”

Key Specifications and Color Code Identification

5.6k Ohm 0.5watt 5% CFR Resistor

To ensure this resistor perfectly matches your BOM (Bill of Materials), here are the technical parameters:

• Resistance Value: 5.6k $\Omega$ (5,600 Ohms).

• Power Rating: 0.5 Watt (1/2 Watt).

• Tolerance: ±5% (Gold band).

• Type: Carbon Film Resistor (CFR).

• Color Code: Green, Blue, Red, Gold (Green-Blue-Red-Gold).

• Maximum Working Voltage: 350V.

• Operating Temperature Range: -55°C to +155°C.

Why Choose 0.5W Carbon Film for Precision Biasing?

Carbon Film Resistors like the 5.6k Ohm 0.5watt 5% CFR Resistor are manufactured by coating a ceramic rod with a thin film of pure carbon. This process yields a component with high dielectric strength and excellent resistance to moisture. The choice of a 0.5W rating over a smaller 0.25W version is often a design decision for “safety by overhead”—running a resistor at only a fraction of its rated power prevents thermal noise and resistance shifting. At BuyCircuitParts, our resistors are finished with a tough lacquer coating to prevent oxidation of the carbon layer.

Common Applications for the 5.6k Ohm Resistor

The 5.6k Ohm 0.5watt 5% CFR Resistor is an incredibly versatile component:

1. Audio Gain Control: Setting the closed-loop gain in operational amplifier (Op-Amp) circuits.

2. Transistor Biasing: Establishing the stable operating point for BJTs in switching and amplification stages.

3. LED Drivers: Limiting current for high-efficiency LEDs in 12V or 24V power systems.

4. Pull-up Resistors: Providing a strong pull-up for open-collector outputs in industrial sensors.

5. Active Filters: Acting as the resistive element in Sallen-Key or multiple-feedback filter topologies.

Pro-Tips for Circuit Integration

To ensure your 5.6k Ohm 0.5watt 5% CFR Resistor provides the best performance, follow these professional tips:

• Current Handling: For 5.6k Ohms at 0.5W, the maximum continuous current is approximately 9.4mA. For precision analog signals, try to keep the actual current below 5mA to minimize “self-heating” noise.

• Color Code Check: Always verify the third band: Green (5), Blue (6), Red (x100). Be careful not to confuse it with Orange (56k) or Brown (560 Ohm).

• Mounting for Heat: Even though it is a low-power resistor, mounting it slightly above the PCB surface (1-2mm) allows air to flow around the body, which is a best practice for high-reliability industrial builds.

• Soldering Advice: The tinned copper leads on our resistors are optimized for both leaded and lead-free solder, ensuring a bright, reliable joint with minimal flux residue.

Why Buy from BuyCircuitParts?

As a specialized seller, we understand that even a ±5% tolerance resistor must be consistent across batches. At BuyCircuitParts, our 5.6k Ohm 0.5watt 5% CFR Resistor stock undergoes strict quality audits to ensure the carbon film is uniform and the leads are robust. We provide components that are easy to identify, easy to solder, and built to last. Our fast shipping ensures your prototype or production line stays “on track” without delays.

Durability and Thermal Stability

The 5.6k Ohm 0.5watt 5% CFR Resistor is designed to withstand the rigors of modern electronics. Its ceramic core provides excellent mechanical strength against vibration, while the flame-retardant coating adds an extra layer of safety. Whether you are building a custom guitar pedal, a laboratory instrument, or a home automation hub, this resistor provides the consistent 5.6k Ohm value you can depend on. By choosing BuyCircuitParts, you are investing in quality passives that protect your active semiconductors.

📐 Dimensions (Approx):
Length: 9.2 mm × Diameter: 3.2 mm
Lead Length: ~28 mm (can be trimmed)

🧊 Note:
Product colour and markings may vary slightly based on manufacturer and batch. Functionality is guaranteed. (Refer to the product image for illustration only. For precise specifications, consult the datasheet.) For a detailed breakdown of resistor technology and standards, visit the Resistor Technology Wikipedia Page.

Explore more high-quality components like this at BuyCircuitParts, your one-stop shop for all electronic needs.
