FR107 Fast Recovery Diode 1000V 1A DO-41 – High Quality

Description

FR107: High-Quality Fast Recovery Diode 1000V

📃 Full Description:
The FR107 is a fast recovery rectifier diode in a DO-41 axial package, capable of withstanding up to 1000V reverse voltage with a forward current of 1A. It has a reverse recovery time of around 500ns, making it faster and more efficient than general-purpose rectifiers like the 1N4007. This diode is widely used in high-frequency circuits, especially where fast switching and efficient rectification are needed.
The FR107 is perfect for SMPS, LED drivers, battery chargers, solar inverters, and other electronic devices that require fast and reliable rectification with moderate current needs.

✅ Key Features:
Type: Fast Recovery Rectifier Diode
Maximum Reverse Voltage: 1000V (VRRM)
Average Forward Current: 1A (IF)
Peak Surge Current: 30A
Reverse Recovery Time: ~500ns
Package: DO-41 Axial
Storage and Operating Temperature: -55°C to +150°C
RoHS Compliant

⚙️ Applications:
Switching Power Supplies (SMPS)
LED Drivers
Battery Chargers
Inverter Circuits
Freewheeling Diode in Inductive Loads
High-speed Rectification Circuits
Solar Power Systems

📐 Dimensions (Approx):
Length: 5.2 mm × Diameter: 2.7 mm
Lead Length: ~28 mm (trim to fit)

📝 Note:
Product image is for illustration; always refer to the official datasheet for accurate specifications.
