M3x6mm Phillips Pan Head Screw with Built-in Washer – Heat Sink Mounting Screw (TO-220 / TO-3P)

Description

This M3 × 6mm Phillips Pan Head Screw (HEAT SINK M3X6 MM) with a built-in serrated washer is designed for secure and vibration-resistant mounting of electronic components like TO-220 and TO-3P packages (e.g., 7805, LM317, 2SC5200, 2SA1943, IRF540). The integrated washer improves grip and distributes pressure evenly on the component tab or mica insulator.

Made of nickel-plated or stainless steel, this screw resists corrosion and ensures a firm fit in aluminum or metal heat sinks. Widely used in SMPS, amplifier boards, LED drivers, and other power circuits.

🔧 Key Features:

• Size: M3 × 6mm
• Head Type: Phillips pan head
• Built-in serrated washer for better hold
• Material: Zinc- or nickel-plated steel
• Rust-resistant, durable, and reusable
• Perfect for use with mica insulators and thermal paste
• Common in DIY electronics, kits, and repair jobs

---

📦 Applications:

• Mounting TO-220 packages (7805, LM317, IRF540, TIP122)
• Securing TO-3P components (2SC5200, 2SA1943)
• Heat sink mounting with mica insulator
• Use in audio amplifiers, SMPS, inverter boards
• Electronics assembly, maintenance, and repair

---

📐 Dimensions:

Washer: Fixed serrated flange
Thread Diameter: M3 (3mm)
Length (under head): 6mm
Head Type: Pan head with cross (Phillips) drive

🧊 Note:
Product colour may vary slightly depending on batch and availability. Functionality remains the same. (Refer to the product image for illustration only. For exact specifications, please check the datasheet.)
